SPECIFICATION
| Blade diameter | Ø150 mm |
|---|---|
| Maker standard | USA |
| Max. knife stroke | 30 mm |
| Side approach type | Tilting side approach |
| Side closed stroke | 7 mm (controllable) |
| Working pressure | 3~6 bar |
| Max. slitting speed | 2000 m/min |
| Min. slitting width | 45 mm |
| Max. paper cutting capacity | 800 g/m² |
| Max. film cutting capacity | 1.5 mm |
Customer-specified knife holders and OEM knife holders are available.
