Shear Cut Knife Holders
General-purpose enhanced shear cut knife holder
DF50 further improves application range and operating capability based on DF40. It is a pneumatic shear cut knife holder for web slitting that requires higher speed and stronger material adaptability. Compared with the smaller base model, DF50 offers a longer stroke, higher speed and a wider material range for medium-speed continuous slitting of paper and film.
| Blade diameter | Ø90 / Ø150 mm |
|---|---|
| Max. knife stroke | 30 mm |
| Side closed stroke | 3 mm |
| Working pressure | 3~6 bar |
| Max. slitting speed | 800 m/min |
| Min. slitting width | 53 mm |
| Quick-change adaptor | G1/8" ~ 28 |
| Max. paper cutting capacity | 500 g/m² |
| Max. film cutting capacity | 1.5 mm |
