Crush Cut Knife Holders
High-strength heavy-duty crush cut knife holder
IT-140 is a high-strength pneumatic crush cut knife holder for thick materials, hard materials and high-speed applications. It uses a high-strength, high-pressure design for heavier loads than regular crush cutting, and it is one of the heavy-duty products in the INT crush-cut series.
| Max. knife stroke | 30 mm |
|---|---|
| Max. air pressure | 10 bar |
| Max. slitting speed | 2000 m/min |
| Max. crush force | 180 kgf（10 bar） |
| Max. paper cutting capacity | 2000 g/m² |
| Max. film cutting capacity | 3 mm |
| Max. foam cutting capacity | 60 mm |
| Min. slit width | 50 mm |
| Blade diameter | Ø150 mm |
